Automatic Bottle Unscrambler
The fully automatic bottle unscrambler machine is suitable for plastic bottle unscrambling and conveying in the agrochemical, daily chemical, pharmaceutical and other industries. For example, 10-500ml plastic bottles can be unscrambled and conveyed. Different specifications require replacement of specification parts, which can be customized according to customer needs.
| Bottle unscrambler | Data |
| Capacity | 3000-4000bottles/hour |
| Application | 10-500ml plastic bottle( different size bottles need change different molds) |
| Machine size | 3800x1700x1800mm |
| Machine weight | 800kgs |
| Power | 1.1kw |
| Voltage | 220V/50HZ (can be customized） |
Main device component configuration
No. | Name | Type or Material | Supplier |
1 | PLC | FX3U-30MT | Japan Mitsubishi |
2 | touch screen | GS2107 | Japan Mitsubishi |
3 | Gear reducer motor | 100YYJT180 | JINWEIDA host motor |
4 | Gear reducer motor | 90YYJT90 | JINWEIDA feed bottles |
5 | photoelectric switch | E3X-NA11 | Japan Omron |
6 | other electrical components | France Schneider | |
7 | container box | components (304 #) | CHENGPAK |
8 | Feed bottle | components | CHENGPAK |
9 | bottle organization | components | CHENGPAK |
10 | transmission mechanism | components | CHENGPAK |
11 | board | components (A3 outsourcing 304 #) | CHENGPAK |
12 | side panels, panel | components (304 #) | CHENGPAK |
Show us your bottle picture to check if it is suitable for this automatic bottle unscrambler machine here: whatsapp 8615317668435
